S03 Electronic control cellular shades closed together to the bottom

Model: S03

Name: Motorized Cellular Shades between glasses

Description: Electronic control cellular shades closed together to the bottom

Slot (width: 40mm)

Tempering Glass (thickness optional: 5, 6, 8, 12mm)

Black Glue (thickness: 8mm)

Cellular Shades (full shading or half shading)

Minimum Size: 315mm* 200mm

Maximum Size: 1500mm*1500mm (for roof)

         1500mm*2500mm (for window/door/wall)

Products Thickness: 5mm+27A+5mm (standard)

Operating Voltage: 24V



For: Sunlight room, middle partition, hotel,

villa, office, hospital, skylights (below 1M2 )…etc


Highlights:


cellular shades can be lifted from the bottom to the top, can stay at any level, which will build a private and lighted space.


No holes in cellular shades for max private.


Fill the gas argon into twi-glass for energe conservation and sound & heat insulation.
